Brand Name : Vanwin Tracking
Model Number : VW-386
Certification : CE/FCC/RoHS
Place of Origin : Shenzhen, China
MOQ : 5pcs
Price : negotiated
Payment Terms : Western Union, T/T, Paypal
Supply Ability : 5,000pcs per month; Universal Mount Infrared Adjustable Angle Rear View Back Up Camera with Anti-Glare Shield
Delivery Time : 2-3 days for samples, 5-10 days for large orders
Packaging Details : Neutral giftbox, with foam plastic bag packed, customize brand is available when order reach 100pcs
Type : back up camera
Resolution : 720P/960P/1080P optional
TV system : PAL or NTSC
IR Cut : YES
Test Time : Over 48 hours
Chip Mode : AHD camera or analog camera
IR lights : 18pcs
Material : Metal housing
Universal Mount Infrared Adjustable Angle Rear View Back Up Camera with Anti-Glare Shield
Camera Specification
Sensor | 1/2.7" SC2035 + NVP2441H |
TV System | PAL / NTSC |
Effective Resolution | 1920(H)×1080(V) |
Minimum Illumination | 0.01 LUX / F1.2 |
Horizontal Resolution | AHD: 2.0 MP 1080P,Analog: 2000 TVL |
Day&Night Mode | External control (default)/automatic/color/black and white |
Frame Rate | 1080P@25fps / 1080P@30fps |
Synchronization Method | inter-sync |
Shutter | AUTO /1/50~1/50000s |
SNR | >46dB |
Video Output | AHD/TVI/CVI/CVBS Switchable |
Working Temperature | -20 º C to 60 º C |
Working Humirity | less than 90 % |
Power | DC12V (±10%) |
Our Advantages
1. 720P/960P/1080P AHD Camera for optional ,also analog chips like CMOS/CCD to choose
2. We also have our own SMT chip factory ,who provides all kinds of chips and mainboard for cameras and MDVR suppliers.
3. We can give you best price as we can ,and also very good quality products.
4. Please trust on us that many clients have ordered over 100 sets after samples testing .
5. We provide of all kinds of cameras and monitors for choice .
Welcome you to test strictly .
Product Dimension
Universal Mount Infrared Adjustable Angle Rear View Back Up Camera with Anti-Glare Shield Images |
